Electrical Specifications |
|
Model No. |
G15201C |
Frequency Range |
1575±5MHz |
Gain |
28Dbi |
VSWR |
≤2.0 |
Input Impedance |
50Ω |
Polarization |
Right-handed circularly polarized |
DC Voltage |
3.3V±0.3V |
Lightning Protection |
DC Ground |
Mechanical Specifications |
|
Connector Type |
Fakra Connector |
Cable Type |
RG174 Black |
Cable Length |
3M |
Working Temperature |
-40℃~﹢65℃ |
Antenna Weight |
85g |
Size |
50*38*15mm |
Installation |
Magnetic adsorption |
Color |
Black |
